Sanwa PGS-LH Low Profile Brushless Servo (High Voltage)

107A54471A

out of stock



Product no.: 023042
normal price € 168.9 (4,391.4 Kč)
our price without Tax : € 132.2 (3,438.0 Kč)
our price including Tax (21 %):
€ 160.0 (4,160.0 Kč)

into the basket:
  pcs

Full specifications

This is the Sanwa PGS-LH Low Profile Brushless High Voltage Servo.



Features:

·         SSL-Compatible Programmable Servo; *Compatible with CODE 10 (M12S, EXZES ZZ, MT-44) Not Compatible with CODE 5 (M12, EXZES Z, MT-4S, MT-4, MT-S)

·         PGS Setting Gear-Compatible

·         Super Response (SSR) Mode-Compatible

·         High Response (SHR) Mode-Compatible

·         LiPo 2S Compatible

·         Low Profile

·         High Speed

·         Brushless Motor

·         Full Aluminum Case

·         Full Metal Gear (Strengthening Gears)

·         Aluminum Heat Sink

·         Programmable Servo to be compatible with SSL & Telemetry at Launch

·         Setting Adjustment by wireless from Radio

·         Setting Adjustment to connect Servo with Setting Gear

·         Regarding Temperature, Current, Voltage and Volume Position on Servo inside, Telemetry-transmission can be passed to Radio.

*Initial Setting on Setting Gear is necessary.



Specifications:

Speed (7.4V)

0.09 sec/60°

Speed (6.0V)

0.11 sec/60°

Torque (7.4V)

15.6 kg/cm

Torque (6.0V)

12.8 kg/cm

Dimensions

40.2x20.5x26.0mm

Weight

53.0g



Settings:

·         SSL-CH (SSL Channel Setting)

·         STRETC (Stretcher Adjustment)

·         BOOST (BOOST Adjustment)

·         D-Band (Dead Band Adjustment)

·         MV-MID (Middle Torque Adjustment)

·         MV-END (Later Torque Adjustment)

·         BREAK (Break Adjustment)

·         MV-HOLD (Power Adjustment at whole area)*

·         MV-FRQ (Feeling Adjustment at whole area)*

·         MAX-PW (MAX Duty Adjustment)*

*Setting Gear is necessary for setting.
