Hobbywing QuicRun 10BL120 G2 BLS Sensored ESC

Full specifications

QuicRun series 120A electronic speed controller (ESC) for sensored motors with built-in powerful switched BEC circuit 6V-7.4V/4A designed for touring and drifting cars or 1:10 RC buggies. Power supply 2-3S LiPo, ideal for sensored motors size 3650/540 (2S ?4.5T/3S ?10.5T).
The QUICRUN 10BL120 G2 Sensored G2 120A controller offers everything you need to fully exploit the potential of your 1:10 RC car with a sensored motor - on-road touring, drifting or off-road buggy. It offers a wide range of 12 programmable parameters for perfect adaptation of the motor, chassis and track. So, if you're serious about driving your beefed-up "tenth" with a brushless motor, the QUICRUN 10BL120 G2 Sensored G2 ESC from Hobbywing is for you!

Features

Specially developed for 1:10 on-road and off-road RC cars: 1:10 touring, buggy, drifting with sensored (but also sensorless) brushless motors powered by 2-3S LiPo/5-9 cells NiMH
For motors: 2S LiPo power: 3650/540 size motors with more than 4.5 turns (≥4.5T) / 3S LiPo power: 3650/540 size motors with more than 10.5 turns (≥10.5T)
Compact dimensions, low weight, high efficiency fan
Ideal in combination with Hobbywing QUICRUN 3650SD G2 sensored motors
12 programmable parameters including Boost and Turbo timing 0-32°
Powerful switched BEC stabilizer up to 4 A with selectable voltage 6.0 or 7.4 V
Advanced protection functions (voltage protection, thermal protection, fail-safe, etc.)
Programmable with LED programming box or LCD programming box G2
Programmable parameters

General: Driving mode, Voltage protection, BEC voltage, Motor rotation direction
Throttle control: Start-up, Max. reverse power, Throttle neutral range
Brake control: Resistance brake intensity, Max. braking effect
Timing: Boost timing (0-32°), Turbo timing (0-32°), Turbo timing delay,
The controller set includes: QUICRUN 10BL120 Sensored G2 controller with cables, operating instructions.

Application Car
Type AC
Continuous current [A] 120
Max. peak current [A] 760
Li-Po [cells] 2 - 3
BEC voltage [V] 6 - 7.4
BEC current (max.) [A] 4
Length [mm] 44
Width [mm] 36.8
Height [mm] 32.3
Weight [g] 101.5
Regulation Bidirectional
Sensor input Yes
Programmable Yes
Water resistance No
